Swing Over Table
|
15"
|
Centre Distance
|
24"/40"/60"/80"
|
Max. Grindng Diameter
|
14"
|
Max. Table Load
|
300 lbs
|
Wheel Dia Dia x W x B
|
16" x 2" x 5"
|
Swivelling Angle R&L
|
+/- 30 Deg
|
Infeed Travel
|
9.6"
|
Handfeed Travel
|
7.9"
|
Topslide Travel
|
7"
|
Wheel Spindle Motor
|
7.5 hp
|
Electrics
|
230/3/60
|
Weight
|
10,500 lbs
|
Heavily ribbed Box Type Base
|
Hydraulic,Coolant & Lube Systems
|
are Seperate From Machine
|
Sturdy Workead offer Variable Speeds:
|
From 30-350rpm & Swivels +/-90'
|
4MT Robust Taisltock With Hard Sleeve
|
Cartridge Type Wheel Spindle With
|
4 class 7 Super Prec Ang Bearings
|
Incorporated with 7.5hp motor
|
One V and One Flat Hand Scraped
|
Guideway, Trucite Coated & Autolube
|
Special Upper Slide Design adds 7"
|
of Travel to the wheelhead
|
Autolube system For
|
Leadscrews & Slideways
|
PLC Menu Driven LCD Control
|
220/3/60 Electrics
|
QAI Certified to CSA SPE 1000
|
Manual
|
