X,Y,Z Axis, Variable Feeds
|
X,Y,Z Axis Rapid Traverse
|
One Shot Lube
|
Coolant System With Chip Tray
|
Light
|
Pendant Control
|
Swivel Table
|
Arbor Support
|
220/3/60 Electrics
|
Certified to CSA SPE 1000
|
Manual
|
Table Size
|
73" x 13.7"
|
Long, Travel (X)
|
58.25"
|
Cross Travel (Y)
|
15.75"
|
Vertical Travel (Z)
|
20"
|
Max. Weight on Table
|
1320 lbs
|
Spindle Taper - VERT
|
ISO 50
|
Spindle Taper - HOR
|
ISO 50
|
Spindle Speeds (12)
|
45-1960 rpm V
|
Spindle Speeds (12)
|
48-2160 rpm H
|
Voltage
|
220/3/60
|
Motor - VERTICAL
|
5.5 hp
|
Motor - HORIZONTAL
|
7.5 HP
|
Weight
|
7,500 lbs
|
